Handles KK

Plastic handle for screwing onto the housing wall, springs back automatically.

Material and surface:
Holder and handle made of heavy duty polyamide PA6, glass ball reinforced, black, similar to RAL 9005, semi gloss, with fine structure. Arbors and restoring sprinds made of stainless steel.

Scope of delivery:
Including black galvanized cross recessed countersunk flat head screws (chromium VI free) M6x30 DIN 965 (German industrial standard), nuts DIN 934 with washers DIN 125.

Other colour versions or combinations available on request.

Stress resistance:
min. 300 N.

show more show less
Unit of measure
Order-No. KK-18.120.84 3D+CAD
