Functional handles FG10

Machine handle with ringilluminated push buttons for switching functions and adjustable handle shanks.

Material and surface:
Handle ledge Ø30x1.5 mm made of stainless steel tube, material no. 1.4301, fine ground. Housing of pushbuttons made of aluminium AlMgSi 0.5; black anodized. Handle shanks made of polyamide PA6, black with fine structure.

Function elements:
2 push buttons up to 1A and red or green illuminated ring. Other LED colours on request. Type FG10-05 with additional emergency stop (2 NC contacts).

Protection class:
IP 54 with screwed on coupling.

Connection:
8 or 12-pole coupling available with 10m ready made cable.

Note:
Other handle lengths, laserinscription below the push buttons and illuminated emergency stop on request.

show more show less
  • handle lengths customized
  • button assignment according to customer requirements
  • button / LED colors according to customer specifications
  • further connection possibilities
  • labeling possible
  • further color versions
show more show less
Unit of measure
Product Type Description Order-No.
Product Type Description Order-No.
Product Type FG10-00 Description Counter handle without function Order-No. FG10-00.300.37 3D+CAD
Product Type FG10-02 Description with 2 push buttons, without emergency stop button Order-No. FG10-02.300.37 3D+CAD
Product Type FG10-05 Description with 2 push buttons, with emergency stop button Order-No. FG10-05.300.37 3D+CAD
Handle accessories
Length Coupling 8-pole (M12 x 1)
Order-No. 		12-pole (M12 x 1)
Order-No.
Length Coupling 8-pole (M12 x 1)
Order-No. 		12-pole (M12 x 1)
Order-No.
Length 10 m Coupling angled 8-pole (M12 x 1)
Order-No. FZ-KS.W08.10 		12-pole (M12 x 1)
Order-No. FZ-KS.W12.10
Length 10m Coupling straight / axial 8-pole (M12 x 1)
Order-No. FZ-KS.G08.10 		12-pole (M12 x 1)
Order-No. FZ-KS.G12.10
