Maniglie funzionali FG16-19

Capacitive handle with optical feedback by green LED. The handle switches reliable by touching the back. The electronics in the handle are wear-free and therefore extremely durable.

Material and surface:
Handle shanks made of high strength polyamide PA6, black with fine structure. Handle ledge made of lathed PVC, black.

Function elements:
FG16-19S:
Capacitive sensor (NO contact)

FG16-19O:
Capacitiver sensor (NC contact)

FG16-00:
Opposite handle without switching elements.

Connection:
4-pole connector positioned at the tubular axle of the handle ledge in the handle shank. Coupling with 10m ready-made cable available as accessory.

Protection class:
IP 54 with coupling screwed on.

Leggi altro mostra di meno
unità di misura
Tipo di prodotto Descrizione N. d'ordine
Tipo di prodotto Descrizione N. d'ordine
Tipo di prodotto FG16-00 Descrizione Contromaniglia senza funzione N. d'ordine FG16-00.150.84 3D+CAD
Tipo di prodotto FG16-19O Descrizione Capacitive sensor (NC contact) N. d'ordine FG16-19O.150.84 3D+CAD
Tipo di prodotto FG16-19S Descrizione Capacitive sensor (NO contact) N. d'ordine FG16-19S.150.84 3D+CAD
Accessori maniglia
Lunghezza Giunto 4 poli (M12 x 1)
N. d'ordine
Lunghezza Giunto 4 poli (M12 x 1)
N. d'ordine
Lunghezza 10 m Giunto angolato 4 poli (M12 x 1)
N. d'ordine
FZ-KS.W04.10
Lunghezza 10 m Giunto diritto / assiale 4 poli (M12 x 1)
N. d'ordine
FZ-KS.G04.10
